Brand Name : SANY
Place of Origin : China
MOQ : 1
Price : USD30000 - USD120000 EXW
Payment Terms : L/C,T/T
Delivery Time : in two weeks
Packaging Details : Bulk Cargo Shipping
Vertical Reach : 42.5m
Horizontal Reach : 37.8m
Max Theoretical Output : 120m³/h
Max Theoretical Pressure : 13MPa
Engine Max Net Power/Speed : 244KW / 1900r/min
Engine Power Rating : 250KW
Engine Displacement : 8.7L
Dimension(L*W*H) : 11500*2550*3960mm
Total Mass : 29000kg
| Category | Specification Details |
| Model | SYM5290THBES (SANY Chassis) |
| Boom System | 5-section RZ-type folding boom |
| Vertical Reach | 42.5m |
| Horizontal Reach | 37.8m |
| Gross Mass | 29000kg |
| Kerb Mass | 23870kg |
| Dimension(L*W*H) | 11500*2550*3960mm |
| Theoretical Output | 120 m³/h |
| Max Pumping Pressure | 13 MPa |
| Engine | SANY/Cummins ISB6.7 (250 HP), Euro V compliant |
| Engine Max Net Power/Speed | 244KW / 1900r/min |
| Engine Power Rating | 250KW |
| Engine Displacement | 8700mL |
| Chassis Configuration | SANY 6×4 heavy-duty chassis |
| Outrigger System | X-type front + V-type rear, automatic leveling (span: 8.8m front, 8.2m rear) |
| Delivery Pipeline | 125mm diameter, high-chrome alloy wear-resistant pipes |
| Control System | SANY EPC intelligent control + wireless remote (1km range) |
| Hydraulic System | Open-circuit system with load-sensitive control |
| Fuel Capacity | 400L |
| Operating Conditions | -20°C to 50°C ambient temperature |
| Safety Features | Boom anti-collision system, emergency stop, automatic pressure protection |





1:What are your main export construction machineries?
A:Used concrete mixer truck,Used trailer concrete pump,Used concrete line pump,Used Truck mounted concrete pump,Concrete batching plant,used cranes,used excavators,used road machinery, used piling machinery and so on.Ranging second-hand original machineries to refurbished machineries .
2:Is your company a factory or a trader?
A:We are re-manufacturing factory with a big used construction machinery trading platform.we specialize in construction machinery wholesale and concrete machinery re-manufacturing for more than 13 years.
3:What are the advantages of re-manufacturing machineries and what quality of your refurbished machineries?
A:The big advantage is price of used machine,value of new machine.We set the highest maintenance and re-manufacturing standard system,strictly inspect and repair according to the standard,Our each re-manufacturing will go through 14 processes from admission test to final inspection to make sure the best quality.
4:How do I know the condition of the original used or re-manufacturing concrete pump truck?
A: We will provide a video of the specifications and the test of the pump truck before we ship to you.
5:What is the minimum order quantity for your used machinery?
A: The MOQ is 1 unit.
|
|
